Product details
| Management number | 221431332 | Release Date | 2026/05/03 | List Price | $17.20 | Model Number | 221431332 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- AceCrew Industrial grade Electric Solenoid Valve Normally Closed
- Size 1 inch NPT thread ,Voltage 110VAC , 120VAC
- Brass inlet & outlet NPT Thread , easy to install with 2-way 2-position direct lift diaphragm
- Normally Closed operation for gas and liquid flow control. Valve will open for flow when energized. Flow rate Cv = 12 ; Unidirectional (indication on brass body)
- Pipe Size : 1" NPT Female (11½ TPI) . Orifice Diameter : 1" (25 mm) Seal/Diaphragm : NBR (Buna-N, Perbunan, and Nitrile rubber)
- Current : 0.2 Amp . Wattage : 24 Watt . Operating Pressure Differential : 0-145 psi (0-1 MPa, gravity-feed capable)
- Suitable for Low viscosity fluid, Water, air, natural gas, propane, butane, petroleum oil, mineral oils, diesel. Not Suitable for gasoline.
- Operating Temperature : 15-125 °F (-10~50 °C). To avoid damaging the coil , this valve is not recommended to be in continuous use for more than 8 hours in a single cycle. Media Temperature : 15-180 °F (-10~80 °C) .
- Weight of solenoid valve : 2 lb 4 oz
| UPC | 784099902284 |
|---|---|
| Size | 1 inch NPT |
| Brand Name | Ace Crew |
| Unit Count | 1.0 Count |
| Valve Type | Diaphragm Valve, Solenoid Normally Closed 1 inch 110vac |
| Thread Size | 1 inch |
| Thread Type | NPT |
| Manufacturer | Ace Crew |
| Model Number | Normally Closed 1 inch 110V, 120V AC |
| Material Type | Brass port, Coil : Copper wire in resin-molded casing, Seal/Diaphragm : NBR (aka Buna-N, Perbunan, and nitrile rubber) |
| Connector Type | DIN 43650-A |
| Item Type Name | Normally Closed Solenoid Valve 1 Inch 110VAC |
| Exterior Finish | Brass |
| Item Dimensions | 5 x 4 x 4 inches |
| Number of Ports | 2 |
| Maximum Pressure | 145 Pound per Square Inch |
| Specification Met | DIN, National Pipe Thread Standard |
| Included Components | Brass NPT thread body 1 Inch Normally Closed, Electromagnetic Coil Solenoid 110V, 120V AC |
| Inlet Connection Size | 1 Inches |
| Inlet Connection Type | FNPT |
| Outlet Connection Size | 1 Inches |
| Outlet Connection Type | FNPT |
| Manufacturer Part Number | 1" 120V AC NC |
